Additional Information
Product Description
| Model | Indoor (50Hz) | CS-S24RKH-1 |
|---|---|---|
| Outdoor (50Hz) | CU-S24RKH-1 | |
| Refrigerant Type | R410A | |
| Cooling Capacity | Btu/h | 21,300 (3,820-24,200) |
| kW | 6.25 (1.12-7.10) | |
| EER | Btu/hW | 11.3 |
| Noise Level | Indoor (H/L/Q-Lo) (dB-A) | 45/34/31 |
| Outdoor (dB-A) | (52) | |
| Phase | ø | 1 |
| Electrical Data | Voltage (V) | 230 |
| Running Current (A) | 8.6 | |
| Power Input (W) | 1,880 (320-2,200) | |
| Moisture Removal | L/h | 3.5 |
| Pt/h | 7.4 | |
| Air Circulation (Indoor/Hi) | m3/min. | 18.1 |
| ft3/min. | 640 | |
| Dimensions | Height (mm) | 296 (695) |
| Height (inch) | 11-21/32 (27-3/8) | |
| Width (mm) | 1,070 (875) | |
| Width (inch) | 42-5/32 (34-15/32) | |
| Depth (mm) | 241 (320) | |
| Depth (inch) | 9-1/2 (12-5/8) | |
| Net Weight | kg | 12 (46) |
| lb | 26 (101) | |
| Refrigerant Pipe Diameter | Liquid Side (mm) | ø 6.35 |
| Liquid Side (inch) | 1/4 | |
| Gas Side (mm) | ø 15.88 | |
| Gas Side (inch) | 5/8 | |
| Pipe Extension | Chargeless Pipe Length (m) | 10 |
| Maximum Pipe Length (m) | 20 | |
| Maximum Elevation Length (m) | 20 | |
| Additional Refrigerant Gas* (g/m) | 20 | |
| Power Supply | Indoor | |
| Cleaner Air | nanoe-G | Yes |
| Anti-Bacterial Filter | No | |
| Odour-Removing Function | Yes | |
| Removable, Washable Panel | Yes | |
| Catechin Air Purifying Filter | No | |
| Solar Refreshing Deodorizing Filter | No | |
| Cleaner Air | nanoe-G | Yes |
| Odour-Removing Function | Yes | |
| Removable, Washable Panel | Yes | |
| Comfort | iAUTO-X | Yes |
| iAUTO | No | |
| ECONAVI | Yes | |
| Temperature Wave | Yes | |
| AUTOCOMFORT | Yes | |
| Inverter Control | Yes | |
| Quiet Mode | Yes | |
| Soft Dry Operation Mode | Yes | |
| Personal Airflow Creation | Yes | |
| Airflow Direction Control (Up Down) | No | |
| Manual Horizontal Airflow Direction Control | No | |
| Manual Airflow Direction Control (Left Right) | No | |
| Convenience | 24-Hour Dual ON OFF Real Setting Timer | Yes |
| 24-Hour ON OFF Real Setting Timer | No | |
| LCD Wireless Remote Control | Yes | |
| Wired Remote Control | No | |
| Reliability | Random Auto Restart (32 Restart Patterns) | Yes |
| Blue Fin Condenser | Yes | |
| Long Piping (Numbers indicate the maximum pipe length) | 20m | |
| Top-Panel Maintenance Access | Yes | |
| Self-Diagnostic Function | Yes | |
| NOTE | Caution For CS-S10/S13/S15/S18/S24/S28RKH-1 (Important) Please do not use copper pipes that are less than 0.6mm in thickness. *When pipes are not extended from the standard pipe length, the required amount of refrigerant is already in the unit. | |
