| Model Number |
TH-32F336M |
| GENERAL ITEMS |
OSD LANGUAGES |
English, Arabic,Persian,French,Portuguese |
| MANUAL LANGUAGES |
English |
| SUPPLY TYPE |
CBU |
| DESTINATION |
Middle East |
| FC COLOUR |
Black |
| TUNNING |
NUMBER OF PROGRAMS |
ATV: 100
DTV: 500 |
| COLOUR SYSTEM |
PAL/NTSC |
| SOUND SYSTEM |
BG / I / DK / M |
| DTV SYSTEM |
DVB-T/T2 |
| BASIC INFO |
CPU |
- |
| GPU |
- |
| OS |
- |
| MEMORY FLASH |
- |
| INTERNET LINK |
- |
| PICTURE |
RESOLUTION |
1366*768(HD) |
| ASPECT RATIO |
4:3/16:9/Zoom1/Zoom2/Just Scan |
| DNR (Noise Reduction) |
Yes |
| Picture Mode |
Yes |
| AUDIO |
AUDIO OUTPUT POWER (RMS) |
8W+8W(Typ.) |
| SPEAKER TYPE |
intergrated speakers(6Ω) |
| FEATURES |
HOTEL MODE |
YES |
| PANASONIC LOGO |
YES |
| CEC |
YES |
| SOUND OUT(ARC） |
YES |
| DIGITAL DOLBY |
YES |
| CONNECTIVITY |
RF IN |
YES |
| DTV IN |
YES |
| AV1 IN |
YES |
| AV2 IN |
NO |
| AV OUT |
NO |
| DVD COMPATIBILITY (YPbPr/YCbCr) |
NO |
| USB INPUT (3.0 SUPPORT) |
NO |
| USB INPUT (2.0 SUPPORT) |
1 |
| HDMI INPUT(2.0 SUPPORT) |
2 (HDMI1.4) |
| HEADPHONE OUT |
1 |
| PC AUDIO IN |
NO |
| PC(VGA IN) |
NO |
| MHL |
NO |
| AUDIO OUT |
NO |
| SPDIF OUT |
SPDIF OUT(COAXIAL) |
| RJ-45 |
YES |
| ANY OTHER (PLEASE SPECIFY) |
NO |
| MULTIMEDIA SUPPORT |
USB DEVICE SUPPORT |
FAT16, FAT32, NTFS(Read only) DO NOT SUPPORT NTFS COMPRESSD FILE |
| PICTURE FORMAT |
JPEG, BMP,PNG |
| AUDIO FORMAT |
MP3 |
| VIDEO FORMAT |
Mpeg1/2,H.264,VC1,HEVC,Mpeg4 |
| PANEL SPECIFICATIONS |
PANEL MODEL NO. AND TYPE |
O/C: BOE/HV320WHB-N86 |
| SCREEN SIZE & DIAGONAL |
32” |
| ASPECT RATIO |
16:09 |
| RESOLUTION |
1366(H) x768(V) |
| DISPLAY AREA(H x V) |
697.685mm(H)x392.256mm(V) |
| PIXEL PITCH |
0.51075mm(H)x0.51075mm(V) |
| DISPLAY COLOURS |
16.7M |
| CONTRAST RATIO |
1200:1(Typ.) |
| MAX BRIGHTNESS |
230(Typ.) |
| VIEWING ANGLE (HORIZONTAL / VERTICAL) |
176°(H)/176°(V)((Typ.) |
| WEIGHT AND DIMN. |
NET WEIGHT WITH PEDESTAL |
4.2kg |
| NET WEIGHT W/O PEDESTAL |
4.1kg |
| NET DIMENSIONS WITH PEDESTAL |
727.3mm x 175.0mm x 476.3mm |
| NET DIMENSIONS W/O PEDESTAL |
727.3mm x 83.0mm x 431.5mm |
| GROSS DIMENSIONS (PACKING BOX) |
808mm x 131mm x 509mm |
| GROSS WEIGHT (WITH PACKING BOX) |
5.6kg |
| RATING |
OPERATING VOLTAGE |
100V-240V~ at 50/60Hz |
| POWER CONSUMPTION |
TBD |
| STD BY POWER CONSUMPTION |
<0.5 W |
| ACCESSORIES |
REMOTE |
53LC-260403-W000 |
| BATTERY |
2 "AA" Batteries |
| POWER CORD TYPE |
DETACHABLE |
| POWER CORD |
UL94V -0 |
| POWER PLUG |
VDE-2PIN; BS-3PIN |
| REGULATION |
BIS |
No |
| CB |
YES |
| ERP |
YES |
| EMC |
YES |
| BEE |
YES |
| ANY OTHER (PLEASE SPECIFY) |
No |
